Durr EcoBell2 SL DC - High-Speed Rotating Atomizer
The EcoBell2 SL DC is a high-speed rotary atomizer designed for electrostatic application of paint or non-electrostatic painting, offering up to 20% increased transfer efficiency compared to air spray guns. Engineered for high paint flow rates and fast painting speeds, this atomizer delivers superior coating uniformity and maximum application efficiency.
Powered by an air turbine, the EcoBell2 SL DC features direct charge technology, where high voltage is applied directly to the paint material for optimized electrostatic performance. This technology enhances transfer efficiency, reduces material waste, and ensures consistent high-quality finishes.
Why Choose the EcoBell2 SL DC?
High-Speed, High-Flow Performance: Optimized for fast and efficient coating processes.
Industry-Leading Transfer Efficiency: Achieves up to 95% transfer efficiency, reducing material waste.
Versatile Application: Suitable for electrostatic and non-electrostatic coatings.
Advanced Technology: Dual shaping air system, automatic paint tube centering, and modular design.
Robotic & Machine Compatibility: Designed for integration into automated systems.
Certified for Industrial Safety: ATEX-certified for hazardous environments.
For high-speed, high-efficiency electrostatic painting, the EcoBell2 SL DC is the ideal solution. Contact us today for more details and to place your order!
Weight:
4.500 g
Diameter Electrode Ring:
165 mm (6,5”)
Length Atomizer:
229 mm (9”)
Air Pressure max. (dyn.):
8 bar (116 psi)
Air Pressure min. (dyn.):
6 bar (87 psi)
Solids Diameter max.:
5 μm
Spray Distance:
220 mm (8,7”)
Recom. Spray Speed:
0,2 - 0,6 m/s
Speed Range:
8.000 - 70.000 rpm
Recom. Speed Range:
15.000 - 55.000 rpm
Flow Rate Fluid max.:
700 ml/min. (11,1 gal/h)
Recom. Flowrate Fluid, min.:
80 ml/min (5,55 gal/h)
Recom. Flowrate Fluid, max.:
350 ml/min (5,55 gal/h)
Fluid Pressure Inlet max.:
20,0 bar (290 psi)
Air Consumption Turbine, min.:
100 Nl/min (3,5 sft3/min)
Air Consumption Turbine, max.:
730 Nl/min (25,8 sft3/min)
Air Consump. Motor Bearing:
50 Nl/min (1,8 sft3/min)
Consump. Shaping Air 1 max.:
520 Nl/min (18,4 sft3/min)
Consump. Shaping Air 2 max.:
480 Nl/min (17,0 sft3/min)
Recom. Consump. Shaping Air:
100-350 Nl/min
Recom. Consump. Shaping Air (US):
3,5-12,4 sft3/min
Viscosity max.:
180 mPas
Rel. Humidity max.:
65 ±5 %
Constant Current:
5 - 50 μA
High Tension:
80 kV
ATEX Marking:
Ex II 2G T4
Optimized for High Paint Flow Rates: Ensures efficient and uniform coverage.
Superior Transfer Efficiency: Achieves up to 95% transfer efficiency, minimizing paint waste.
High-Speed Application: Designed for fast and precise industrial coating processes.
Versatile Use: Compatible with both robotic and machine applications.
Quick-Change Technology: Enables fast maintenance and reduced downtime.
Dual Shaping Air System: Provides optimized atomization control for fine finishes.
Automatic Paint Tube Centering: Enhances coating precision and consistency.
Modular Design: Simplifies economic maintenance and part replacements.
Optimized Bell Disk Purging: Ensures clean operation with minimal contamination risk.
ATEX Certified (Ex II 2G T4): Safe for use in hazardous environments.
The EcoBell2 SL DC is designed for high-precision electrostatic and non-electrostatic painting, making it ideal for:
Automotive Industry: High-speed application of base coats, primers, and clear coats.
Industrial Coating: Electrostatic painting of metal and plastic components.
Aerospace & Heavy Machinery: Uniform coating of large and complex surfaces.
Automated & Robotic Painting Systems: Compatible with robotic arms and high-speed production lines.
With high-speed operation, electrostatic efficiency, and precise control, this atomizer maximizes coating quality while reducing paint consumption.
To enhance functionality and ensure optimal performance, the following EcoBell2 SL DC accessories are available:
Atomizer Components:
N34850018 – Add-on unit atomizer war RP 60° Px245 LI
N34770091 – Flange Package EcoBell2 SL WAR EWS L5m
N44050010 – Atomizer Seat L140 EcoBell
Control & Safety Equipment:
N65040001 – Hand Earthing Stick
N32040146 – Control Valve 1x 4x6 9x12 SE4 cpl.
N34960001 – Controller Connection Kit for EcoBell2
